Model | Medium | displacement | ℃ Inlet Tempralture | MPa Inlet Pressure | MPa Outlet Pressure | T/h Cooling water consumption | KW Shaft power | KW Motor power | |
M³/min Suction condition | M³/h Standard condition | ||||||||
ZW-100/30 | Oxygen/ nitrogen | 100 | 6500 | 25 | 0.02 | 3.0 | 150 | 1065 | 1250 |
ZW-96/7 | oxygen | 96 | 6000 | 25 | 0.015 | 0.7 | 80 | 590 | 630 |
ZW-84/30 | oxygen | 84 | 5200 | 25 | 0.015 | 3.0 | 120 | 850 | 900 |
ZW-86/8 | oxygen | 86 | 5000 | 35 | 0.01 | 0.8 | 80 | 530 | 560 |
ZW-80/18 | 80 | 4800 | 25 | 0.01 | 1.8 | 100 | 700 | 800 | |
ZW-78/30 | 78 | 4700 | 25 | 0.01 | 3.0 | 120 | 780 | 850 | |
ZW-75/30 | 75 | 4500 | 30 | 0.012 | 3.0 | 100 | 755 | 800 | |
ZW-78/28 | 78 | 4200 | 25 | 0.01 | 2.8 | 80 | 720 | 800 | |
ZW-64/22 | 64 | 4000 | 22 | 0.015 | 2.2 | 80 | 620 | 710 | |
ZW-68/30 | 68 | 3800 | 30 | 0.05 | 3.0 | 82 | 650 | 710 | |
ZW-60/20 | 60 | 3600 | 25 | 0.01 | 2.0 | 70 | 540 | 630 | |
ZW-60/30 | 60 | 3600 | 25 | 0.01 | 30 | 80 | 590 | 650 | |
ZW-56/30 | 56 | 3450 | 25 | 0.015 | 3.0 | 80 | 580 | 630 | |
ZW-56/2.5 | 56 | 3300 | 20 | 0.01 | 0.25 | 25 | 200 | 220 | |
ZW-56/26 | 56 | 3300 | 25 | 0.01 | 2.6 | 70 | 535 | 630 | |
ZW-52/30 | 52 | 3200 | 30 | 0.015 | 3.0 | 80 | 550 | 630 | |
ZW-46/30 | 46 | 2800 | 30 | 0.015 | 3.0 | 70 | 490 | 560 | |
ZW-42/30 | 42 | 2500 | 25 | 0.01 | 3.0 | 60 | 420 | 500 | |
ZW-38/16 | 38 | 2400 | 30 | 0.02 | 1.6 | 50 | 325 | 355 | |
ZW-36/30 | 36 | 2300 | 25 | 0.02 | 3.0 | 50 | 370 | 400 | |
ZW-40/16 | 40 | 2200 | 40 | 0.03 | 1.6 | 50 | 325 | 355 | |
ZW-33/18 | 33 | 2000 | 20 | 0.01 | 1.8 | 50 | 290 | 315 | |
ZW-36/30 | 36 | 2000 | 25 | 0.05 | 3.0 | 50 | 350 | 400 | |
ZW-35/16 | 35 | 1700 | 40- | 0.05 | 1.6 | 50 | 260 | 315 | |
ZW-30/5 | 30 | 1700 | 30 | 0.03 | 0.5 | 30 | 150 | 180 | |
ZW-28/30 | 28 | 1600 | 30 | 0.01 | 3.0 | 50 | 285 | 320 | |
ZW-14/9 | 14 | 800 | 40 | 0.01 | 0.9 | 20 | 98 | 110 |
