43 cylinders per hour oxygen compressor(oil free)

  • Product name: oxygen cylinder filling oxygen compressor
  • Model:ZW-4.3/ 165 oilfree: Medium
  • Dry oxygen: Flow rate
  • ~6.5t/h : Power of electric motor
  • 90KW:

We're here to help:

Easy ways to get the answers you need.

chat
  • 43 cylinders per hour oxygen compressor
  • Technical Data
  • Specifications
  • Inquiry

Type        :Vertical,

three-rank,
five-stage,
oil-free lubrication,
water-cooling and piston Exhaust capacity  4.3 m3min (according to suction state)
Medium :  Dry oxygen Discharge condition: Pressure16.17MPa
Cooling water:Inlet water temperature   <32℃
flow  rate :      ~6.5t/h
Piston travel   180 mm
Revolution of compressor      :260r.p.m
Motor Model       Y315M-6
Power of electric motor           90KW
Matching motor: 380V (three phase)    50Hz

 Type        :Vertical,

three-rank,
five-stage,
oil-free lubrication,
water-cooling and piston Exhaust capacity  4.3 m3min (according to suction state)
Medium :  Dry oxygen Discharge condition: Pressure16.17MPa
Cooling water:Inlet water temperature   <32℃
flow  rate :      ~6.5t/h
Piston travel   180 mm
Revolution of compressor      :260r.p.m
Motor Model       Y315M-6
Power of electric motor           90KW
Matching motor: 380V (three phase)    50Hz
